CONFIGURATION OF THE MAIN UNIT (CG-100EX/130EX)
Front of the main unit
Rear of the main unit
1) Tray
Small articles can be placed on it.
Note that the cutter has to be kept out of reach of children since it can be dangerous.
2) Operation panel
The device is operated and functions are set on the operation panel.
3) Sheet set lever
Tilting the lever away from you lowers the pinch rollers to retain the sheet of medium.
