LISTING OF FUNCTIONS
The device is provided with the following functions.
Refer to chapter 3 for how to select and enter the functions.
Functions invoked with the jog keys (arrow keys)
The jog function is used to move the top end of a tool to a given location to set coordinates of the
plotter.
Item Description of function
Origin select Specifies an origin for cutting (plotting).
Cutting area setting Specifies an area, in accordance with the sheet to be used, within which cutting
(plotting) is performed.
Axis alignment Aligns the axis of the sheet to be used with that of the device.
Paper cut Cuts off the sheet of media.
Digitize Sends a given coordinate to the host computer.
Functions invoked with specific keys
Item Description of function
Tool select Sets a tool to be used to a cutter or pen.
Data clear Clears data being cut (plotted).
Auto feed Feeds the sheet of medium by the amount to be used.
Hold Corrects displacement of the sheet being used for cutting (plotting).
Functions
Item Description of function
No. copies Performs cutting according to the received data on two or more sheets of medium.
Square cut Performs cutting of a square to verify that cutting conditions are appropriate.
Distance compensation Compensate an error in cutting length.
Set up Specifies functions.
Sample cut Performs cutting of characters “Cut” to determine whether or not the device is faulty.
Dump execution Plots data sent from the host computers in the ASCII data format.
List Plots tool conditions or function setting conditions.
Display Changes over the language to be displayed on the LCD.
