– 1.8 –
ATTACHING THE ROLL HANGERS (CG-60EX)
Mount the roll hangers following the procedures described below.
1) Fit the right-hand roll hanger to the
main unit.
Align the projection of the roll hanger with the
corresponding hole in the main unit.
Secure the roll hanger on the side plate with a
hexagon head bolt using a hexagon wrench key
supplied with the unit.
2) Mount the left-hand roll hanger follow-
ing the same procedure as described
above.
