– 3.27 –
Tool lifting speed setting [UP SPEED]
This function is used to establish a traveling speed of the sheet and carriage to be employed when
the tool placed in the carriage is in the raised position.
If a lower speed is specified, displacement of the sheet will be eliminated at the time of long-
distance feed.
Setting value (Make a choice and input it)
5, 10, 20, 30, 40, 50, 60, 70, 80, AUTO (cm/s)
• If the [AUTO] is specified, the SPEED setting established in the tool conditions
will be employed. It should be noted, however, the minimum SPEED setting will
be 10 cm/s.
Change-over of jog steps [JOG STEP]
This function is used to select the amount of travel of the carriage and sheet when the jog key (arrow
key) is pressed.
In the following cases, accurate positioning will be enabled.
• When performing two-point axis alignment.
•When performing digitization.
• When establishing an origin at a desired location with accuracy.
Setting value (Make a choice and input it)
For “mm”:
1.0: A press on the jog key will move the carriage and sheet by 1.0 mm.
0.1: A press on the jog key will move the carriage and sheet by 0.1 mm.
For “inch”:
1/16: A press on the jog key will move the carriage and sheet by 1.0 mm.
1/254: A press on the jog key will move the carriage and sheet by 0.1 mm.
