– 3.25 –
Device pin CCITT
number V.24
4RSCA105 RTS out Normally ON (1)
5CSCB106 CTS in Normally ON (1)
6DRCC107 DSR in Depends on the interface cable
20 ER CD 108/2 DTR out Normally ON [HARD].
OFF: In the case where the
buffer is almost full at the
time of a handshake.
JIS C6361 RS-232C etc. Direction Remarks
CUT1
*
1254KB
*
RS1 CS0 DR0 ER0
Setting value (Make a choice and input it)
PANEL : The device operates using the setting established on its operation panel.
HOST : The device operates using the setting established by the command setting function
of the host computer.
Remote display [REMOTE DISP]
This function is used to specify the display to be shown on the LCD panel under the remote mode.
Normally, [NORMAL] is specified.
Setting value (Make a choice and input it)
NORMAL : The tool specified and remaining amount of data on cutting appear on the
LCD panel. The remaining amount of data will increase at the receipt of data
from the host computer, or decrease upon execution of cutting.
RS-232C : Status of signal conductor of RS-232C appears on the LCD panel. This is
helpful in case of a trouble in connection.
In the case of NORMAL In the case of RS-232C
