– 3.41 –
Sheet setting [SHEET SET]
In the case where a heavy sheet or wide sheet is to be used, the sheet setting is performed using the
sheet setting function to avoid displacement of the sheet.
In the case where the [SHEET SET] is set to “HEAVY,” the maximum speed that can be specified
will be 20 cm/s and the acceleration will be a half of the normal value.
Setting value
NORMAL · HEAVY
* If a heavy sheet or wide sheet is cut (plotted) at a high speed, “ERR41 MOTOR
B” can arise. In addition, slippage of the sheet can occur.
Setup resetting [SETUP RESET]
This function is used to return settings of all items including tool conditions and distance compensation
to the initial settings factory-settings at the time of delivery.
The settings that have been established as initial ones remain in memory even if the power is turned
off.
