A7™ Service Manual 046-006272-00 4 - 23
Calibration System Calibration
FIGURE 4-34 Pneumatic connection with the calibration device (TSI Certifier 4070)
11.Press the Accept button and the screen shown below is displayed.
• The screen shown below is displayed after a successful flow sensor calibration.
FIGURE 4-35
• The screen shown below is displayed if the flow sensor calibration has failed.
To Next Page
