Gas Flow Theory of Operation
1 - 28 046-006272-00 A7™ Service Manual
FIGURE 1-25
If the system is configured with the anesthesia calculation function, corresponding sampling connec-
tors will be integrated on the ACGO valve block. The positions (under the work surface) of the ACGO
assembly with the two configurations in the system are similar, as shown in the following figure.
FIGURE 1-26
Independent ACGO Outlet
When the ACGO assembly is switched to the ACGO state, the fresh gas will be output from the inde-
