Mindray A9 Operating Instructions

Operator’s Manual of Anesthesia System 7 - 7
Anesthetic Gases and O
2
Concentration Monitoring AG Module Settings
7.7 AG Module Settings
You can do the following settings when the anesthesia system is configured with an external
AG module.
7.7.1 Set Operating Mode
When the anesthesia system enters standby mode, then the AG module will also enter its standby
mode. When the anesthesia system exits from standby mode, the AG module will also exit from its
standby mode and enter measurement mode.
7.7.2 Set AG Flow Rate
To change the AG flow rate:
1. Select the soft key > [AG] soft key.
2. Select the [Flow Rate] soft key.
3. Select an appropriate flow rate.
4. Select to close the dialog box and confirm the changes.
7.7.3 Set CO
2
Unit
To change the CO
2
Unit:
1. Select the soft key > [System] soft key (system password required) > [Setup] >
[Language/Unit] key.
2. Select the [CO
2
Unit] key.
3. Choose between mmHg, kPa and %.
4. Select to close the dialog box and confirm the changes.
7.7.4 Set CO
2
Scale
To change the CO
2
scale:
1. Select the soft key > [AG] soft key.
2. Select the [CO
2
Scale] soft key.
3. Choose the appropriate scale.
4. Select to close the dialog box and confirm the changes.
7.7.5 Set O
2
Scale
To change the O
2
scale:
1. Select the soft key > [AG] soft key.
2. Select the [O
2
Scale] soft key.
3. Choose the appropriate scale.
4. Select to close the dialog box and confirm the changes.
7.7.6 Set N
2
O Scale
To change the N
2
O scale:
1. Select the soft key > [AG] soft key.

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
