Mindray A9 Operating Instructions

Alarm Display Alarms and Messages
8 - 4 Operator’s Manual of Anesthesia System
8.2 Alarm Display
On the LCD monitor screen, alarm messages are automatically displayed on the top of the Main
Screen when alarm conditions are met (see Figure 8-1).Additionally, a list of all active alarms can be
found in the Alarms window (see Figure 8-2).
Each message is displayed with an associated priority symbol as follows:
To display a list of all active alarms:
1. On the Main Screen, select the [Alarms] soft key or touch the Alarm Message area on the top of
the screen.
The Alarms window displays.
2. Select the [Active] tab.
A list of all active alarm messages is displayed (Figure 8-2).
Alarms are displayed in order of priority and time.
Figure 8-2 Active Alarms list in the Alarms window
• High priority
• Medium priority
•Low priority
