Anesthetic Gas Scavenging System (AGSS) Product Specifications
10 - 14 Operator’s Manual of Anesthesia System
10.7.7 Breathing System Temperature Controller
10.7.8 Breathing Circuit Parameters
10.7.9 Unidirectional Valve Opening Pressure
Dry: ≤ 0.12 kPa opening pressure.
Wet: ≤ 0.12 kPa opening pressure.
10.8 Anesthetic Gas Scavenging System (AGSS)
10.9 Negative Pressure Suction device
10°C≤T(Ambient temperature)≤20°C:
∆T=T (Temperature at metal test point of the pressure
sampling body near the inspiratory check valve)-T (Ambient
temperature)≥11°C
20°C≤T Ambient temperature)≤40°C T (Temperature at metal test point of the pressure sampling
body near the inspiratory check valve)≥31°C
10°C≤T(Ambient temperature)≤40°C
∆T=|T (Temperature at test point of Y-piece patient
connection)-T (Ambient temperature)|≤2°C and T
(Temperature at test point of Y-piece patient
connection)≤41°C
Single fault condition T (Temperature at test point of Y-piece patient
connection)≤41°C
Note: The block heater does not operate while the system is being powered by the internal battery supply.
TABLE 10-19
Breathing System Temperature Controller
System Compliance: ≤ 2 ml/cm H
2
O
Resistance: ≤ 6 cmH
2
O
Leakage: ≤ 50 ml/min @ 3 kPa (under BTPS condition)
System Safety Pressure on Breathing
System:
110 cmH
2
O
TABLE 10-20 Breathing Circuit Parameters
Type of the Applicable
Disposable System:
Low flow
Extract Flow: 25 to 50 L/min
Resistance: ≤ 0.05 kPa @ 25 L/min
≤ 0.05 kPa @ 30 L/min
≤ 0.35 kPa @ 50 L/min
≤ 0.35 kPa @ 75 L/min
TABLE 10-21
Anesthetic Gas Scavenging System (AGSS)
Performance Category: Pharyngeal Suction
Gas Supply: External vacuum system
Gas Supply Pressure Range: -72 kPa to -40 kPa
TABLE 10-22 Suction device
