Operator’s Manual of Anesthesia System B - 3
Parameters and Factory Defaults Main Menu
B.3 Main Menu
Alarms: Agents: FiHal Low 0 %
Alarms: Agents: EtEnf High 3 %
Alarms: Agents: EtEnf Low 0 %
Alarms: Agents: FiEnf High 2 %
Alarms: Agents: FiEnf Low 0 %
Alarms: Agents: EtIso High 3 %
Alarms: Agents: EtIso Low 0 %
Alarms: Agents: FiIso High 2 %
Alarms: Agents: FiIso Low 0 %
Alarms: Agents: EtSev High 6 %
Alarms: Agents: EtSev Low 0 %
Alarms: Agents: FiSev High 5 %
Alarms: Agents: FiSev Low 0 %
Alarms: Agents: EtDes High 8 %
Alarms: Agents: EtDes Low 0 %
Alarms: Agents: FiDes High 6 %
Alarms: Agents: FiDes Low 0 %
PARAMETERS DEFAULT
PARAMETERS DEFAULT
Setup: Ventilation: Vt/IBW 7 ml/Kg
Setup: Ventilation: Vt Source IBW
Setup: Ventilation: Time Control I:E
Setup: Ventilation: Pressure Display PLAT
Setup: Ventilation: Plimit Line On
Setup: Ventilation: Breathing System Warmer On
Setup: AG: CO
2
Scale 0-60 mmHg
Setup: AG: O
2
Scale 0-100 %
Setup: AG: N
2
O Scale 0-100 %
Setup: AG: Des Scale 0-9.0 %
Setup: AG: Sev Scale 0-4.0 %
Setup: AG: Iso Scale 0-2.5 %
Setup: AG: Hal Scale 0-2.5 %
Setup: AG: Enf Scale 0-2.5 %
Setup: AG: Flow Rate High
Setup: Screen: CO
2
Location Top
Setup: Screen: Screen Saver 30 min
Setup: System: Setup: Ventilation: Insp Pressure Pinsp
Setup: System: Setup: Quick Key: Alarm Reset On
Setup: System: Setup: Quick Key: Capture Event/Screen On
Setup: System: Setup: Quick Key: Lung Recruitment On

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
