Mindray A9 Operating Instructions

Cleaning and Disinfection Maintenance
9 - 20 Operator’s Manual of Anesthesia System
•Volume Exchanger
• Breathing System Body
• Bag Arm
•O
2
sensor support
•Bypass
•CO
2
Absorbent Canister
• Inspiration connector
• Expiration connector
• Flow sensors
•Inspiration valve
• Expiration valve
• Seals and sealing rings
If the components are damaged, worn and torn, contact your service personnel or Mindray.
9.7.3.4.1 Volume Exchanger
1. As shown in the figure, pull the unlocking button outward.
Figure 9-19 Open the volume exchanger cover
2. Put in the volume exchanger following the screen-printed instructions.
Figure 9-20 Put in the volume exchanger
3. Close the volume exchanger cover.
Unlocking
Button
Volume exchanger

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
