Mindray A9 Operating Instructions

Operator’s Manual of Anesthesia System 10 - 7
Product Specifications Electrical Specifications
10.5.2 Battery Power Specifications
Battery Type: Sealed lead acid battery,
One (1) battery: 12VDC, 16Ah
Two (2) batteries: 12VDC, 32Ah
Battery Run-time: ≥ 90 minutes (powered by one piece new fully-charged battery under the typical
condition)
≥ 180 minutes (powered by two pieces new fully-charged batteries under the
typical condition)
≥ 50 minutes (powered by one piece new fully-charged battery under the worst
power consumption condition)
≥ 100 minutes (powered by two pieces new fully-charged batteries under the
worst power consumption condition)
Typical condition:
• VCV mode: Vt = 500 ml, RR = 10 bpm, I:E = 1:2, Plimit =40 cmH
2
O, PEEP = 0
cmH
2
O, Tpause = OFF
• Electronic Flowmeter is in working condition (Total flow: 2.0L/min; O2%: 50%)
• Screen brightness: Default Value
• Alarm volume: Default Value
• Key tip tone: Default Value
•Dome light: OFF
• Sampling rate of Anesthetic Gas Monitoring Module: 150mL/min
• Auxiliary Flowmeter is in working condition (Total flow: 2.0L/min; O2%: 50%)
• Active Electronic AGSS is in working condition
• Gas Supply Rated Working Pressure: 400kPa±100kPa
• Resistance: 20cmH
2
O/L/s
• Compliance: 20mL/cmH
2
O
Worst power consumption condition:
• VCV mode: Vt = 2000 ml, RR = 30bpm, I:E = 4:1, Plimit =100 cmH
2
O, PEEP = 50
cmH
2
O, Tpause = OFF
• Electronic Flowmeter is in working condition (Total flow: 18.0L/min; O2%:
50%)
• Screen brightness: Brightest
•Alarm volume: Highest
•Key tip tone: Highest
• Dome light: High
• Sampling rate of Anesthetic Gas Monitoring Module: 200mL/min
• Auxiliary Flowmeter is in working condition (Total flow: 15.0L/min; O2%: 50%)
• Active Electronic AGSS is in working condition
• Gas Supply Rated Working Pressure: 400kPa±100kPa
• Resistance: 20cmH
2
O/L/s
• Compliance: 20mL/cmH
2
O
Time to Shutdown
from Lower
Battery Alarm:
5 minutes at least (powered by new fully-charged batteries after the first low-
power alarm)
Battery Charge
Time:
New Battery: < 12 hours (powered by new depleted batteries at 25°C ambient
temperature under typical working mode).
TABLE 10-6
Battery Power Specifications

Mindray A9 Specifications

General

Brand	Mindray
Model	A9
Category	Medical Equipment
Language	English
