Mindray A9 Operating Instructions

Equipment Views Product Description
2 - 10 Operator’s Manual of Anesthesia System
PARTS DESCRIPTION
C1 Installing rail Used to install the standard attachment arms of the monitor and
other equipment. Installing rails are available on both sides of the
equipment.
C2 High-flow Nasal
Cannula Oxygen
(HFNC) outlet
Used to output O
2
when the High-flow Nasal Cannula Oxygen
(HFNC) feature is enabled.
C3 Module slot Used to be inserted with and recognize the AG module mentioned
in this manual.
C4 AGSS flow control knob Rotate the knob clockwise or counter clockwise to adjust the flow
in the AGSS until the float in the Status Screen is located between
Min and Max scale lines.
C5 Sample gas return port The sample gas return port of the Gas module.
C6 Auxiliary high-pressure
O
2
outlet
Used to connect to an external device (such as an air-jet ventilator)
for hyperbaric O
2
venting.
C7 Oxygen sensor cover
switch
Used to open the O
2
sensor cover.
C8 Handle The maximum force capacity of the handle is 10 kgf (22 lbf).
WARNING: The handle in intended to be used for installing
and dissembling the breathing system only and
shall not be used for pushing/pulling/lifting the
anesthesia system.
C9 Handle The handle is intended to be used for pushing/pulling/rotating the
anesthesia system, with a maximum force capacity of 80 kgf (176
lbf).

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
