5-30 Image Optimization
5.8 Anatomical M Mode
 Items that appear in the menu or the soft menus are dependent upon preset, which
can be changed or set through "[Setup] -> [Image Preset]"; please refer to "5.16
Image Preset" for details.
CAUTION:
Anatomical M images and Color Anatomical M images are
provided for reference only, not for confirming a diagnosis.
Please compare the image with that of other machines, or make
diagnosis using none-ultrasound methods.
5.8.1 Free Xros M Mode
For an image in the traditional M mode, the M-mark line goes along the beams transmitted
from the probe. Thus it is difficult to obtain a good plane for difficult-to-image patients that
cannot be moved easily. However, in the anatomical M mode, you can manipulate the
M-mark line to move to any position at desired angles. The system supports anatomical M
scanning (including Free Xros M mode and Free Xros CM mode) in 2D imaging modes (B,
Color, Power and TVI mode).
5.8.1.1 Imaging
 Shortcut key for Free Xros M mode
Assign a user-defined shortcut key for Free Xros M: [Setup] -> [System Preset] -> [Key
Config]. Please refer to "14.1.7 Key Config" for details.
 Real-time Imaging
1. In real-time B mode or M mode, adjust the probe and image to obtain the desired
plane.
2. Click in the bottom-left corner of the screen to enter Free Xros M mode,
or press the user-defined key.
3. Adjust the M-mark (single or multiple) line to obtain optimized images and necessary
information.
In Dual-split or Quad-split mode, it is the current activated window that enters the
Free Xros M Mode.
 Imaging in Freeze Mode
1. Free Xros M imaging of images in cine memory: Click , or press the
user-defined key directly.
2. Adjust the M-mark line (single or multiple) and image parameters to obtain optimized
images and necessary information.
5.8.1.2 Free Xros M Image Parameters
 In Free Xros M mode imaging, the image parameter area in the upper left corner of
the screen displays the real-time parameter values as follows:
Display G 62 V 3
Parameter Free Xros M Gain Free Xros M Speed
