Barcode Reader C-1
Appendix C Barcode Reader
The product supports two kinds of readers for logging data as patient ID: 1-D barcode
reader (SYMBOL LS2208) and 2-D barcode reader (SYMBOL DS6707). The laser
transmitted by the two readers is Class 2 laser.
WARNING:
Class 2 laser adopts low power, visible LED.
DO NOT stare into beam because of unknown
hazards of transient radiation provided by
class 2 laser.
CAUTION:
Ensure the information acquired by barcode
reader is consistent with the actual
information.
There are 2 operation modes:
Hand-held mode: press the trigger to decode.
Hands-free mode: seat the reader in the stand to enter the mode, the reader decodes
automatically.
Note: the reader does not support decoding of Multilanguage.
C.1 1-D Barcode Reader
C.1.1 Overview
1.
LED Green: A barcode was successfully decoded.
Red: A data transmission error or reader malfunction occurred.
2.
Scan window
Scan the barcode.
3.
Trigger Press to decode
