Mindray M6 User Manual

2-16 System Overview
2.8.3 V/A Extend Module
 Overview
The module is connected to the USB port of the main unit via a USB cable.
< >
1
< >
2
< >
3
< >
4
No. Name Function
<1>, <2> Audio input port Used for audio signal input
<3> Composite video input port
Used for composite signal video input
(Reserved)
<4> Separate video input port
Used for separate signal video input
(Reserved)
 Connection
Connect the V/A extend module to the main unit via a USB port. As shown in the following
figure.
