11-4 DICOM
Name Description
AE Title
Application entity title of the ultrasound system.
The AE title here should be the same with the one of the acceptable SCU set
in the server.
Port
DICOM communication port, which should be the same with the one in the
server.
PDU
Maximum PDU data package size ranging from 16384 to 65536. The default
value is 32768.
Log
Setting
File Name: name of the DICOM log, generated by the system automatically.
Log Level: to set the log type.
The available selections: No log, Service result log, Service process log, All
log.
We suggest setting “All log”, so that you can see the DICOM log on the E
disk.
OK Click to confirm parameter setting.
Cancel Click to cancel parameter setting.
Enter AE Title, Port, PDU according to the actual situation, and then click [OK] to exit the
screen.
Tips:
AE Title should be the same with the SCU AE Title preset in the server (PACS/
RIS/ HIS), for example, if the AE Title of the server preset in the storage server is
AAA, and the AE Title of the accepted SCU is preset as MMM, then in the figure
above, the AE Title of Local should be MMM, and the AE Title of storage server
should be AAA.
Same IP Address may result in DICOM abnormality.
11.1.3 DICOM Server Setting
To add or delete DICOM servers, or set IP address and name for the DICOM server.
1. Press <Setup> to enter the Setup menu.
2. Move the cursor onto [Network Preset]; select [DICOM Server] to open the screen, as
shown in the figure below.
