Probes and Biopsy 12-25
NGB-027
12.2.3 Biopsy Preset
Enter the biopsy preset page: [Setup]→[System Preset]→“Biopsy”.
Bracket preset
To set the default bracket for a probe:
1. Select a probe model in the Probe Model list, all the supported bracket models will be
displayed in the “Bracket Model” list on the right side. (If the selected probe has no
bracket matched, no model is displayed.)
2. Click to select a bracket model on the Bracket Model list.
3. Click [OK] to confirm the setting and return to Setup menu.
Parameter preset
To set if to display/hide guide line and dot type.
1. Check [Guide Line Display] to set the guide line display, otherwise, the guide line is
hidden when enters biopsy status.
2. On “Guide Line Dot Type” column, select a dot type among Small, Medium and Big.
3. Click [OK] to confirm the setting and return to Setup menu.
Intra-cavity probe
Pinch nut
Position
block
Front clamp
Front slot
Lower clamp
Positioning block
To Next Page
