C-2 Barcode Reader
C.1.2 Setting up the Reader (Take LS2208 as an
example)
1. Plug the interface cable modular connector into the cable interface port on the bottom
of the reader handle, and ensure the connector is properly secured.
2. Connect the other end of the interface cable to the host.
1.
Cable interface port
2.
Interface cable modular connector
C.1.3 Setting
The reader has factory settings; please refer to A.4 for details.
The reader supports some user-defined functions as introduced below.
For more details, please contact the SYMBOL reader agents or Mindray Customer
Service Department.
 Volume setting:
Scan the following barcode to set the volume parameter.
 code 93 and codebar scanning:
To enable or disable Code 93, scan the appropriate barcode below.
To Next Page
