Mindray M6 User Manual

Probes and Biopsy 12-5
12.1.2 Orientation of the Ultrasound Image and the
Probe Head
The orientation of the ultrasound image and the probe are shown as below. The “Mark”
side of the ultrasound image on the monitor corresponds to the mark side of the probe.
Check the orientation before the examination (Here takes linear probe as an example).
Mark
Orientation mark

Mindray M6 Specifications

General

Brand	Mindray
Model	M6
Category	Medical Equipment
Language	English
