Mindray M6 User Manual

2-12 System Overview
No. Name Function
1. Display module
Displays the image and parameters during
scanning
2. Probe cable hook Probe cable hanger
3. Ultrasound system /
4. Probe holder Used for placing probes temporarily
5. Operating platform To place the ultrasound system
6.
Adjustable telescopic column
switch
Raise the handle to adjust height of the
platform
7. Built-in DVD RW drive DVD-RW drive
8.
Compartment for placing ECG
module or B/W printer
/
9.
Compartment for placing color
printer
/
10. Caster Used for securing or moving the system
11. Display support arm
Supports the display module, for adjusting
the height and position of the display
module.
12. I/O extend module To extend I/O ports
13. Probe port To connect probe or probe extend module.
14. Adjustable telescopic column To adjust height of the operating platform
15. Probe extend module To extend ports for connecting probes
16. Power adapter /
17. Power module
Power supply input/output interface,
equipotential terminal, breaker and power
indicator
