5-52 Image Optimization
Type Parameters Description
Other
Operations
Undo
To undo the last cut only.
Undo All To undo all cuts since you entered image edit mode.
Measurement
2D related measurement can be performed. For details, please refer to [Advanced Volume].
NOTE: capturing preparation does not support the measurement.
5.11.3.4 Image Saving in Static 3D
 Image saving:
 In the 3D Review mode, press <Save> key (with user-defined saving function) to save the
current image and volume data to the patient information management system in the set
format.
 Save cine: in 3D viewing mode, press the user-defined save key to save CIN-format clip to the
hard drive.
 Image review:
Open an image file to enter the image review mode. In this mode, you can perform the same
operations as what you can in review mode.
5.11.3.5 Color Static 3D (Color 3D)
NOTE: the system supports color Static 3D flow imaging function. See Chapter 5.11.4 Color 3D.
5.11.4 Color 3D
Color 3D imaging provides more visualized flow information, especially in heart and kidney application,
which helps in observing cardiovascular diseases.
NOTE: Color 3D is an option, which includes color Smart 3D, color STIC and static 3D flow imaging.
5.11.4.1 Basic Procedures for Color 3D
1. Enter into color 3D image acquisition preparation status:
(1) Obtain a feasible Power/Color image with the volume probe.
(2) Press the user-defined <3D> key, or <4D> key to enter 3D/4D image acquisition preparation
status.
2. Set the acquisition, displaying related parameters, select acquire mode.
3. Press <Update> to begin image acquisition.
4. After the acquisition is completed, the system enters into image view status; you can perform
operations like image edit and storage.
5. Save image as necessary.
5.11.4.2 Operation Controls
Parameter Description
Display
Function: you can choose to display only color images or gray scale images, or
to mix them.
Range: VR, MPR, B, C, B&C.
Priority
Function: to determine color information displayed on gray scale images.
Range: 0-100.
