DICOM/HL7 11-9
Name NOTE
AE Title
Application Entity title. Here, it is consistent with that
of the Worklist server.
Port
DICOM communication port, 104 by default. Here, the
port should be consistent with that of the Worklist
server port.
Maximum Retries Reserved feature.
Timeout
Refers to time after which the system will stop trying
to establish a connection to the service. Value: 5－
60s, in increments of 5, and 15 by default.
TLS
Transport Layer Security. Select whether to encrypt
the data during network transportation.
Strategy Name Select the desired DICOM strategy.
Click to add the Worklist service to the service list.
Cancel Click to cancel the parameter setting.
Update
Select an item in the service list, change the
parameters in the above area, and click [Update] to
update the item in the service list.
Service list
Delete Click to delete the selected service in the service list.
Default
Set the worklist server as the default.
Select an item in the service list, click [Default] and
you can see “Y” in the Default column.
Verify
Click to verify if the two DICOM application entities are
normally connected.
11.1.3.4 MPPS Preset
1. Select [Setup][DICOM/HL7][DICOM Service Setting][MPPS] to enter the MPPS page.
2. Select the device name, and type the information about the AE title, the port.
3. Click [Add]. The entry will be added in the service list.
NOTE:
Set the MPPS service as the default when using the MPPS.
