11-10 DICOM/HL7
MPPS setting items are described as follows:
Configure
new service
Device Name
After you set the server (s) in DICOM Server Setting, the name
(s) will appear in the drop-down list, select the name of the
MPPS server.
Service Name Default is server-MPPS, and it can be modified.
AE Title
Application Entity title. It should be consistent with that of the
MPPS server.
Port
DICOM communication port, 104 by default. Here, the port
should be consistent with that of the MPPS server.
Maximum Retries
It starts retrying if it fails to send DICOM task to the server. The
retry entry times should be this value.
Interval Time(s) Reserved feature.
Timeout
Value: 5－60s, in increments of 5, and 15 by default. The
connection is disabled if there is no message to be sent in 15
seconds after the MPPS being sent.
Add Add the DICOM service to the service list.
Cancel Click to cancel the parameter setting.
Update
Select an item in the service list, change the parameters in the
above area, and click [Update] to update the item in the service
list.
Service list
Delete Click to delete the selected service in the service list
Default
Set the worklist server as the default.
Select an item in the service list, click [Default] and you can see
“Y” in the Default column.
