Minebea Intec Ex Indicator Midrics 1 - Page 18

3
1
2
Legend
Pos. Description
1 Selected menu item (e.g. printer for setting up the connected printer)
2 Menu history (reference to the top menu level in the setup menu)
3 Note that other sub-menus are available
6
7
4
5
Legend
Pos. Description
4 First level in the number menu
5 Second level in the number menu
6 Third level in the number menu
7 Current active setting
3.3.3.3 Navigating in the menu
The keys under which white arrows are applied can be used to navigate in the menu.
Key Description
Back to the superordinate menu level
Call up next menu item in the same level.
Scroll onwards in the same level.
Press for less than 2 seconds: Select and save menu item
Press for more than 2 seconds: Exit menu, switch to measurement mode
Ex Indicator Midrics 1 (MIXS1) 3 Device description
EN-16 Minebea Intec
