— STAND. Standard conguration
(see also Chapter 6.6.1)
— RANGES Standard conguration
— SINGLE Single-range scale
— MULT.INT Multi-interval scale
— MULT.R. Multi-range scale
— UNITS Usable weight units
— SAVE Save settings
Setup information
The ADC conguration is only possible when the locking switch is open. Close the locking
switch after the ADC conguration, otherwise the "overload" ("H") and "underload" ("L")
conditions will not be displayed.
The ADC conguration is carried out when the service mode is activated in the setup
menu under the menu item [SETUP]- [WP-1]- [INTERN]- [ADC-CON] (see also
Chapter 6.6).
Enter max. loads in a suitable weight unit and without decimal places (decimal places are
truncated by rounding).
Note:
Returning to the top menu level of the menu without rst saving the conguration
parameters (menu item Save) deletes all settings entered previously.
The ADC conguration entries are not aected by a menu reset (returning the setup
parameters to factory settings).
Note:
Once the conguration of the A/D converter has been locked, the weighing results can
no longer be inuenced by the indicator.
5.5.3.1 Menu items for ADC conguration
Standard or verication conguration (menu items [STAND.] / [VERIF.])
In the ADC conguration, the rst step is to select whether the weighing platform is to be
congured as a standard or veried weighing platform (for use in legal metrology).
Default conguration: [STAND.].
For the standard conguration [STAND.], the following parameters can be set:
ADC-CON
Descriptions of the individual menu items:
- Range selection (menu item RANGES) (see Chapter 5.5.3.1.1)
- Usable weight units (UNITS menu item) (see Chapter 5.5.3.1.2)
- Save conguration data (menu item SAVE) (see Chapter 5.5.3.1.3)
5.5.3.1.1 Range selection (menu item RANGES)
Depending on the setting under this menu item, the menu items RANGE 1, RANGE 2 and
RANGE 3 are shown or hidden for further conguration (see Chapter 6.6.1).
Single-range scale [SINGLE]:
