— STAND. Standard conguration
(see also Chapter 6.6.1)
— RANGES Standard conguration
— SINGLE Single-range scale
— MULT.INT Multi-interval scale
— MULT.R. Multi-range scale
— UNITS Usable weight units
The entire weighing range is divided into verication intervals according to the smallest
display increment d and the maximum weight. The readability corresponds to the display
increment d.
Multi-interval scale [MULT.INT.]:
The "multi-interval scale" function divides the weighing range into up to 3 ranges with
dierent readabilities. The respective change takes place automatically when the
specied range limit is exceeded. After taring, the best possible resolution (smallest
display increment) is available even with a loaded weighing platform.
Multi-range scale [MULT.R.]:
Scale with two or three weighing ranges. When the range limit of the lower weighing
range is exceeded, the scale switches to the next weighing range up (lower resolution).
The scale can only be switched back to the higher resolution after it has been completely
unloaded.
Display increment d: The display increment d indicates the resolution of the scale. The
entry is only possible in steps 1, 2, 5, 10, 20, etc.
Maximum load (max. load):
The maximum load is the maximum weight that can be loaded onto the weighing
platform. At higher weights, the scale displays overload "H".
The partial increments of the scale are calculated using the maximum load and the
smallest display increment d (e.g.). maximum load = 15,000 kg and smallest display
increment d = 0.005 kg results in 3000 partial increments).
Range 1, range 2, range 3[RANGE 1], [RANGE 2], [RANGE 3]:
The range limits are entered for the individual ranges. When these limits are exceeded,
this aects the accuracy.
The following rule applies for entry: Range 1 < range 2 < range 3 < max. load.
Thus, the weighing range can be divided into up to 4 ranges. The resolution changes at
intervals 1, 2, 5, 10, 20 etc., whereby the lowest resolution is the smallest display step d
entered. Set any areas that are not required to zero.
5.5.3.1.2 Usable weight units (menu item UNITS)
Here you can select the weight units that are to be enabled in the weighing mode. All
units marked with a circle (o) are enabled, and multiple selection is possible (see
Chapter 5.5.3.1.2).
5.5.3.1.3 Saving conguration data (menu item SAVE)
The ADC conguration data is saved once at the end of the setting with [SAVE] (see
Chapter 6.6.1).
5.5.3.1.4 Menu tree for ADC conguration
The menu for WP1 [WP-1] is extended in service mode by the following additional setting
options for ADC conguration:
ADC-CON
