3. Product presentation
MiR500 User guide (en) 09/2019 - v.1.3 ©Copyright 2018-2020: Mobile Industrial Robots A/S. 32
7. Emergency stop button: four
buttons., two on each side
CAUTION
The emergency
stop button is not
intended for
operational stops.
The emergency
stop is only
intended for use in
case of an
unforeseen hazard.
1. Signal light: eight pcs., two on
each corner (see Sensor system
on page51)
8. Button interface
2. Proximity sensors: eight pcs., two
in each corner behind corner
cover (see Sensor system on
page51)
9. Top plate
3. Rear maintenance hatch: opens
to rear compartment (see
MiR500 internal parts on
page36)
10. Bumpers
4. Nonoscan3 safety laser scanner
(see Sensor system on page51)
11. 3D cameras
5. Left cover plate: access to power
interface, GPIO interface and
Ethernet interface
12. Swivel wheel with foot guard
