5-4 Mx-Series Manual
3400 -
3439
The servo motor
power is off due to
linear encoder error.
(Front X-axis)
Manually move the linear motor after
servo off and check the Linear Scale
Read Head.
If the encoder is constantly
recognized, the alarm line of the
encode cable is damaged.
See the circuit drawing for details of
pin layout. If the encoder is not
detected, contact the C/S engineer to
adjust the gap of the linear scale
read head. This setting should be
carefully done by the C/S engineer.
5-34
3440 -
3479
The servo motor
power is off due to
user abort. (Front
Xaxis)
Close the door or restore the
emergency key and retry after Servo
On.
5-26
5-27
3480 -
3519
One or more heights
of Zaxis exceeded the
limit during Front X
Gantry motion.
Check Z-axis origin offset.
5-30
5-37
3520 -
3559
The target position of
the Zaxis DMC is
invalid. Check the
DMC.
Check the Motion Control Board
(DMC) referring to the axis allocation
table.
5-30
5-37
3499 -
3506
The target position of
the Motion Board is
invalid.
Check the Motion
Board. (Z1- Z6)
Check Z-axis origin offset.
5-30
5-37
3518
Front Z-axis motion
error
Check DMC of the axis referring to
the axis allocation table.
5-30
5-37
3519
Z-axis motion error
Check the Z-axis Origin Offset.
Check the DMC referring to the axis
allocation table.
5-30
5-37
4000 -
4008
Serial board
initialization error
(Port1)
1. Try again and check the connector
and the board communication
status.
5-30
Error Code
Message Description
Actions
References
4001-4008
Board initialization
error.
Unwanted data is
continually received.
(Port 0 – Serial
Shell)
Unidentifiable error. Ignore and
continue. If the error is not
resolved, check again after power
Off/On. If the same error occurs
repeatedly, contact the C/S
engineer.
5-30
