Mirae Mx200 - COMPRESSED AIR SPECIFICATION AND CONNECTION

3-4 Mx-Series Operation Manual
Compressed Air Specification and Connection
Specification of compressed air
The table below shows the specification of compressed air required for
the system to operate.
The following parts should be used to meet this specification:
− Oil-free compressor
− Compressed air cleaning/drying system
− X- series micro filter
Specification
Remark
Maximum particle size in compliance with
ISO/DIS 8573-1
(Class 1)
Particle Size
0.1 μm
Density
0.1 mg/m
3
Maximum Oil Particle
Class 1
Density 0.01 mg/m
3
Pressurized Dew Point
Class 4
Dew Point
+ 3℃
<Table 3-1 가 Compressed air specification >
Air Connection Locations
The connector supplies compressed air to the system one-touch-
fitting that air can be easily supplied.
The pressure of the air supplied to the system should be at least 5 or
6 kgf/cm², and the air hose should be Ø16mm in diameter. (A 5m
long, Ø16mm air hose is provided with the system.)
The user can supply or block the compressed air to each part of the
SMD placement system using the cock valve type switch.
