Mirae Mx200 - System Configuration

Chapter 2 Part Description 1-
7
3. Discarding Assembly
Discards parts that can not be normally placed.
System Configuration
Multi-
Tray
Supply
Unit
Y Axis Ass’y
Y Tray Pusher Ass’y
Y Tray Guide-L Ass’y
Y Tray Guide-R Ass’y
Z AXIS Ass’y
Stacker Tray Up-Down
Ass’y
Tray Up-Down Plate
Ass’y
Cover Ass’y
