Operation and Maintenance
196
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Fig. 83 Memory of the Call Manager card CPU1
6. 1. 1. 1 System software
The communication server's entire system software package is stored in compressed
form in the Flash memory.
The RAM components comprise the main memory for program data. When the PBX
starts up, the communication server software on the serial Flash memory is decom-
pressed, loaded into the main memory and started.
6. 1. 1. 2 File system of the communications server
The file system of the communication server comprises the system software, the soft-
ware for system phones, the system and terminal configuration data, the audio data,
system logs, data for WebAdmin, etc. The data is stored in the Flash memory. With
WebAdmin you have access to the file system via the menu item File management.
You can see the file system memory load and then load audio data, languages for the
user interface and online help, language files for Mitel 6700 SIP / 6800 SIP-series SIP
phones as well as an external numbering plan for SIP connection. Moreover, with the
file browser you have the possibility to view, upload, replace or delete the folders and
files in the file system. The file system can also be accessed with an FTP client (see
also "File management", page 190
).
Call Manager card CPU1
EIM card
RAM module
Flash card
