Annex
257
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Digital terminal interface BRI-S
• Standard Euro ISDN interface
• Phantom power supply min. 140 mA, limiting at approx. 170 mA, terminal voltage
36…41 V
• Up to 8 terminals can be connected
• Maximum of 2 simultaneous call connections
Analogue terminal interface FXS
• Configurable multifunctional interface for connecting analogue terminals and equip-
ment.
• The following applies for the FXS mode Phone / Fax, two-wire door and general
bell:
– Voice path with A/D and D/A conversion (standard PCM, A-law)
– Transmission as per ES 201 168 (level country-specific)
– Constant-current loop supply approx. 25 mA (with loop resistance ≤ 1000 Ω)
– Receive pulse or DTMF dialling
– CLIP display on all analogue terminal interfaces (Mitel 415/430 only on 2 ana-
logue terminals simultaneously).
– Ringing supply 40…43 V 50 Hz at load 4kΩ; no DC voltage overlay (country-spe-
cific versions also with 25 Hz)
– No control key detection
– No charge signalling pulses
• For more technical details and cable requirements see "Multifunctional FXS inter-
faces", page 143.
7. 4. 3 Communication server
Tab. 113 Dimensions and weights
Tab. 114 Electrical isolation of interfaces
Mitel 470
Height 85 mm
Width 481 mm
Depth 380 mm
Weight (with call manager card but without mains cord, interface
cards, modules and packaging)
6.71 kg
Interface Mitel 470
Analogue network interfaces 0.2 kV Operating isolation
Digital network interfaces BRI Operating isolation
