Mitel 470 - LAN Switch; Digital and IP System Phones

Annex
259
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Tab. 119 Modules
7. 4. 5 LAN switch
Fig. 94 LAN switch on CPU card CPU1
Fig. 95 LAN switch on the backplane
7. 4. 6 Digital and IP system phones
Tab. 120 Digital and IP system phones
Card Dimensions length x width [mm]
DSP module 90 x 56
IP Media module 85 x 85
Charge module 83 x 60
MiVoice 5360 / 5360 IP, MiVoice 5361 / 5361 IP, MiVoice 5370 /
5370 IP, MiVoice 5380 / 5380 IP, Office 10, Office 25, Office 35,
Office 45/45pro
Ambient temperature in operation 0 °C to 40 °C
Relative humidity in operation 30 % to 80 %
Admissible storage temperature -25 °C to 45 °C
Power consumption, digital system phones see table "Average power requirements of terminals", page 90
and
table "Maximum power requirements of the system phones on the
DSI bus", page 131
Power consumption, IP system phones see System Manual for "Mitel Advanced Intelligent Network (AIN)
and IP system phones"
