Mitel 470 - Installing, Powering, Connecting and Registering Terminals; IP System Phones

Installation
159
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Cable Requirements
Use commercial Cat. 5 cable, or choose a cable type with the following characteristics:
Tab. 78 Requirements for an Ethernet cable
See also:
For more information about the Ethernet interface on the application card, see the CPU2-S
application card installation manual.
4. 8 Installing, powering, connecting and registering termi-
nals
4. 8. 1 IP system phones
Accesses
Tab. 79 Socket connections of the IP system phones of the MiVoice 5300 IP series
Core pairs × cores 4 × 2
Stranded yes
Wire diameter, core 0.4...0.6 mm
Screening yes
Category Cat. 5 minimum
PoE Ethernet interface for connection to the IP network
Socket connection for a workstation PC (integrated 100Base-T switch, available on MiVoice 5370 IP
and MiVoice 5380 IP)
Handset socket
Headset socket
Power supply socket for connecting a power supply if PoE is not available
Connect expansion key module MiVoice M530⁄MiVoice M535 (available on MiVoice 5370 IP and
MiVoice5380IP)
