Expansion Stages and System Capacity
63
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Tab. 29 Max. admissible current input at USB interfaces
Access to the applications server is normally via the WebAdmin configuration tool,
which means the front-side interfaces of the applications card are not needed.
Note
For licensing reasons the front-side connections are to be used for maintenance purposes only.
Installing user-specific applications is prohibited.
See also:
For more information about installing, configuring and upgrading the software of the application
card, see the CPU2-S application card installation manual.
3. 4 System capacity
System capacities are defined on the one hand by the existing hardware with its ex-
pansion possibilities and on the other by the limits set in the software. The software lim-
its can be partly expandable by licences.
3. 4. 1 Media resources
3. 4. 2 General system capacity
The number of slots, interface cards and system modules per communication server
have already been mentioned in the previous chapters and are not listed separately in
this chapter.
Note:
The values in the following three tables relate to a communication server with an Mitel 470
Expansion expansion licence. Without this licence the system is limited to the first 36 users in
the numbering plan, which means many values in the table are not valid.
Tab. 30 General system capacity
Front-side USB interfaces Internal USB interfaces Max. current input [mA]
top left / bottom left bottom 100
top right / bottom right top 500
Max. number... Mitel 470
AIN with
Mitel 470 as
Master
Nodes in a transparent network (AIN) – 41
Nodes with SIP networking 100 –
Users 400
1)2)
600
Terminals per user
3)
16 16
Simultaneous connections
