Annex
258
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Tab. 115 Ambient conditions
Tab. 116 Electrical data
Tab. 117 Heat dissipation
7. 4. 4 Dimensions of cards and modules
Tab. 118 Dimensions of cards and fan-out panels
Control input on FXS interface no isolation
Control output on FXS interface no isolation
Audio input on FXS interface no isolation
Condition Mitel 470
Ambient temperature 5 °C to 45 °C
Relative air humidity 30 % to 80 %, non-condensating
Internal power supply
Mitel 470
Auxiliary power supply unit
(APS2)
Class of protection 1 1
Input voltage 103 V...127 V or 207 V...253 V,
48...62 Hz
100 V…240 V, 48...62 Hz
Input current approx. 0.2 A...2.2 A (with 115 V)
approx. 0.1 A...1.1 A (with 230 V)
approx. 0.2 A...4.0 A (with
115 V)
approx. 0.2 A...2.0 A (with
230 V)
Resistant to voltage breaks < 20ms < 20ms
Power input with min. configuration approx. 25 W approx. 25 W
Power input with max. configuration approx. 140 W approx. 260 W
Undervoltage limit
(system reset, data backup)
< 90 V < 90 V
Mitel 470
Basic system with auxiliary power supply unit approx. 140 W = 504 kJ/h
Maximally configured system approx. 400 W = 1440 kJ/h
Card Dimensions width x height x depth [mm]
Interface cards 93 x 41 x 265
Call Manager card CPU1 154 x 41 x 265
Applications card CPU2 154 x 41 x 265
Fan-out panel FOP 481 x 44 x 69
Interface Mitel 470
