Mitel 470 - Terminal Cards

Expansion Stages and System Capacity
60
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Tab. 26 Trunk cards
3. 3. 2. 2 Terminal cards
Terminal cards are used for connecting digital and analogue voice and data terminals
such as:
FXS cards are an exception. Their analogue interfaces are multifunctional. In addition
they provide interfaces for controlling external devices and switching over internal
switch groups. Depending on the terminal or function, the interfaces are configured in-
dividually and switched over internally accordingly (see "Multifunctional FXS inter-
faces", page 143).
DSI cards are used for connecting digital system terminals such as phones. 2 terminals
can be connected to each DSI interface.
Terminals to ETSI standard are connected via BRI cards. The cards contain both termi-
nal interfaces (BRI-S) and network interfaces (BRI-T). On the BRI cards 4 interfaces
can be individually configured to BRI-S or BRI-T.
Type
Network inter-
faces per card
Max. number of
cards per system
Remarks
1PRI 1 × PRI 7
1)
1) 1 fewer card if CPU2 application card is fitted
• Can be fitted with 1 IP media module
• Contains 30 B channels
• 10 B channels can be used licence-free
2PRI 2
× PRI 7
1)
• Can be fitted with 2 IP media modules
• Contains 2
× 30 B channels
• 2
× 10 B channels can be used licence-free
4BRI 4
× BRI-T 7
1)
• All interfaces configurable to BRI-S
8BRI 8
× BRI-T 7
1)
• Four fixed BRI-T interfaces
• 4 BRI-T interfaces configurable to BRI-S
4FXO
2)
2) The availability of the FXO trunk cards depends on the sales channel.
4 × FXO 7
1)
• 1 call charge module can be fitted for 4 ports
8FXO
2)
8 × FXO 7
1)
• 1 call charge module can be fitted for 8 ports
16FXO
2)
16 × FXO 4 • 1 call charge module can be fitted for 16 ports
