30 Using the phone system
Final
4 Connect one end of the phone power pack into your phone and the other
end into a power outlet.
Note: If your network is configured with Power Over Ethernet (POE), the
above step is not necessary.
5 Wait for the phone to display the following (this may take 30 seconds or
more):
6 Press the ACTIVATE softkey.
The display will show:
7 Enter your extension.
8 If you have login/logout privileges, the display will show:
Enter your PIN, then press the ENTER softkey.
9 If you do not have login/logout privileges, the display will show
:
Press the YES softkey.
10 The display will show
:
You have now successfully activated the phone, and can make calls.
See “Quick Set Up” on page 97 for information about initial settings you
should configure through the web interface.
Answering a call
When an incoming call is received on a phone, several things happen: (1) the
phone rings, (2) a Line Appearance flashes, and (3) the LCD displays the
phone number of the caller and, if known, the name of the caller.
You can answer an incoming call by picking up the handset, pressing the
ANSWER softkey, or by pressing the Speaker key on the 5020/5220 IP
phone or the key on the 5224 IP phone.
Logged Out
ACTIVATE
Extension:
QUIT
PIN:
ENTER QUIT
Extension: 314
YES NO
Extension: 314
REDIAL CALLS MENU
