5.2 Master Function
5.2.1 Automatic communication function
5
FUNCTIONS
(b) Data transfer timing in the automatic communication buffer area
Data are transferred for each data exchange with the target station.
(c) Data transfer between the automatic communication function buffer areas and
programmable controller CPU device memory
Data can be transferred between the automatic communication buffer area and
programmable controller CPU device memory by either of the following methods.
* 1 Refer to the following manual for details on the intelligent function module devices.
User's Manual (Function Explanation, Program Fundamentals) for the CPU module used
Table5.3 Data transfer between automatic communication function buffer areas and
programmable controller CPU device memory
Transfer method Description
Transfer by auto refresh setting
Make the auto refresh setting on GX Configurator-
MB.( Section 8.5)
Transfer using the sequence program
Specify the intelligent function module device (Un\G ) in a
sequence program to make transfer.
*1
