8.6 Monitor/Test
8
UTILITY PACKAGE (GX Configurator-MB)
[Specifications common to Monitor and Test screens (including sub screens)]
The following explains the specifications common to respective screens.
(1) Display data
(2) Command buttons
Setting item : Displays I/O signals and buffer memory names.
Current value : Monitors the I/O signal states and present buffer memory values.
Setting value : Enter or select the data to be written by test operation.
Displays the current value of the item selected. (This is
used to check the text that cannot be displayed in the
current value field. However, in this utility package, all
items can be displayed in the display fields.)
Creates a file containing the screen data in text file
format.
/
Selects whether or not to monitor current values.
Performs a test on the selected item.
To select more than one item, select them while holding
down the key.
Closes the screen that is currently open and returns to
the previous screen.
Current value display
Make text file
Start monitor
Stop monitor
Execute test
Ctrl
Close
To Next Page
