6878215A01
1-2 Introduction Mobile Radio Description
NOTE: The rear accessory connector adds 0.75 in to the overall length. The remote mount length
is 194mm.
Figure 1-5. Front View of APX 7500
High Power (100W) Transceiver and Trunnion
Figure 1-6. Side View of APX 7500 High Power (100W)
Transceiver and Trunnion
Figure 1-7. Front View of O2 Control Head
Attached to APX 7500 Mid Power Dash Mount
Transceiver and Trunnion
Figure 1-8. Side View of O2 Control Head
Attached to APX7500 Mid Power Dash Mount
Transceiver and Trunnion
Figure 1-9. Front View of O7 Control Head
Attached to APX 2500 Mid Power Dash Mount
Transceiver and Trunnion
Figure 1-10. Side View of O7 Control Head
Attached to APX 2500 Mid Power Dash Mount
Transceiver and Trunnion
223
74
90
293
206
92
69
278
269
207
194
51
80
178
51
224
