Motorola ASTRO APX O2 - Figure 1-39. Remote Mount Configuration with High Power (100 W) Radio Transceiver, Universal Relay Controller and O7 Control Head (URC Is Optional); Figure 1-40. Remote Mount Configuration with High Power (100 W) Radio Transceiver, Universal Relay Controller and O9 Control Head (URC Is Optional)

6878215A01
1-12 Introduction Standard Configurations
Figure 1-39. Remote Mount Configuration with High Power (100W) Radio Transceiver,
Universal Relay Controller and O7 Control Head (URC is optional)
Figure 1-40. Remote Mount Configuration with High Power (100W) Radio Transceiver,
Universal Relay Controller and O9 Control Head (URC is optional)
For details on these configurations, see Section 2.2.2 on page 2-23.
O7 to URC Cable
17 ft Extension Cable
O9 to URC Cable
17 ft Extension Cable
