6878215A01
Standard Configurations Radio Mounting 2-21
2.2.1 Dash Mount with Trunnion
NOTE: This configuration is not applicable for 100W radios.
1. Referring to Figure 2-6, select the suitable trunnion kit per the type of mid power transceiver.
2. Select the location to mount your radio on the transmission hump (see Figure 2-25) or under
the dash (see Figure 2-26).
NOTE: When mounting the trunnion on the transmission hump take care the transmission housing is
not affected. Plan your installation ensuring enough room for the Accessory connector and
cable in the back of the radio.
3. Using the trunnion mounting bracket as a template, mark the positions of the holes on the
mounting surface. Use the innermost four holes for a curved mounting surface such as the
transmission hump, and the four outmost holes for a flat surface such as under the dash.
4. Center punch the spots you have marked and realign the trunnion in position.
5. Secure the trunnion mounting bracket with the four self-drilling screws provided
(see Figure 2-25 and Figure 2-26).
6. Ensure that the plastic guides are aligned (horizontal) to the grooves of the trunnion. Slide the
radio into the grooves until it snaps into place (see Figure 2-26).
Table 2-6. Mid Power Trunnion Kit
Item Part Number Description Mid Power Transceiver
1
0371859H01 Trunnion Mounting Screw APX 5500/APX 6500/APX 6500 Li/APX 7500
0305760W02 Trunnion Mounting Wing Screw APX 2500/APX 4500
2 0312002B14 Self-Drilling Tapping Screw
APX 5500/APX 6500/APX 6500 Li/APX 7500
APX 2500/APX 4500
3
HLN7002_ Mackinaw Trunnion Hardware Kit APX 5500/APX 6500/APX 6500 Li/APX 7500
HLN6861_ Millenium Trunnion Hardware Kit APX 2500/APX 4500
