I
N
D
E
X
configuring
arbitration mode 6-8
battery backup 1-12, 5-12, 6-4
baud rate 1-7, 2-1
boot memory 5-10, 6-6
boot ROM/Flash write protection 6-5
console 1-6, 2-1, 5-14
debug/test port 6-7
DRAM 1-13, 6-10
DREQ# signal source 6-10
environment parameters 4-2
IDE addressing mode 6-9
PCMCIA 6-10
serial communications 5-14
terminal 1-6, 2-1, 5-14
connecting an external battery 1-10
connectors
location 6-1
See also J12 to J28 for specific connec-
tors.
console configuration 1-6, 2-1, 5-14
console port (J18) 2-1, 5-13
control registers 4-3
conventions used in the manual xviii
cooling requirements A-3
CPU activity LED 6-30
D
debug port
header (J24), pinouts 6-13
selection 6-7
signals 6-7
debugger 3-2
debugger commands 3-3
breaking 2-4
debugger prompt 3-2
diagnostics 2-4, 3-2
diagnostics prompt 3-2
diagrams, board architecture 5-1
dimensions, MBX board A-1
DIMM socket (XU3) 1-13, 5-9, 6-10
disk interfaces 5-15, 5-19
EIDE connector pinouts 6-26
floppy disk connector pinouts 6-28
DMA capability 6-11
documentation, related B-1
DRAM
configuration 1-13, 6-10
installation 1-12
specifications 1-12, 5-9
DREQ# signal source 6-10
E
EBX form factor 5-6
EBX specification B-3
EIA-232 5-17, 6-15
EIDE interface 5-19
connector (J14), pinouts 6-26
entering commands 3-3
entry-level configuration 5-7
entry-level features 5-5
ENV
command 4-2
parameters 4-2
EPPCBug firmware 3-1, 5-10
command execution 3-3
command syntax 3-3
debugger 3-2
debugger commands 3-3
memory requirements 3-2
overview 3-1
EPPC-Bug prompt 3-2
EPPC-Diag prompt 3-2
equipment required 1-1
ESD precautions 1-2
Ethernet
10BaseT connector (J15), pinouts 6-16
AUI header (J20), pinouts 6-16
interface 5-15
station address 5-15
expansion modules
installation 1-7
stacking 1-8, 5-19
