MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
13/70
MultiOne SRL
Ref. Part Function
1 Back-weights (Nr. 2) (optional) Back-weights increases the stability of the machine.
2 Engine It moves the hydraulic pumps.
3 Opening engine space compartment
It protects the engine and prevents the operators in charge to get in touch accidentally
with the mobile parts and high parts.
4 Rear reflectors They make the machine more visible.
5
Driving seat supplied with armrests and
safety belt
It is for the operator to be seated and fastened to the machine.
6 ROPS It protects the operator in case of rolling over of the machine.
7 Control panel
It assembles operating controls of the machine and of the possible attachment assembled
to the machine.
8 Wheels They support and allow the machine movement.
9 Quick coupler It allows the mechanic connection to attachment.
10 Lifting arm It raises possible attachment assembled of the machine.
11 Multiconnector It allows the connection to the attachment hydraulic circuit.
12 Electrical supplying plug DC 12 V
It provides with the supplying of possible electrical devices placed on the assembled
attachment.
13 Working lights They provide more visibility in a situation of poor lighting.
14 Hydraulic circuit pipes They allow the passage of the hydraulic oil for assembled equipping working.
15 Wheel It allows to change direction during the translation of the machine.
16 Roof and FOPS structure
It protects the operator in charge from bad weather and from the direct exposure to the
sunbeams, the FOPS structure (if there is see par. 6.3.1) protects the operator against
the object fall.
17 Document holder Where operator manual and document are placed.
18 Fuel tank cap It allows fuel supplying.
19 Hydraulic oil tank cap It allows the oil control, by means of a graduated oil dipstick.
20 Pedals They allow to determine the direction and speed.
21 Disconnecting battery key It allows to disconnect the battery.
22 Central steering articulation Moved by an hydraulic cylinder allows the steering of the machine.
TAB. 2
DESCRIPTION OF THE MACHINE -4
