MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
MultiOne SRL
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
18/70
Ref. Name Function
6 Parking brake
It is used to block the machine during the parking and the waiting. The brake is of a Pin Lock type
and it operates only on the front wheels.
N.B: the brake is correctly inserted when the noise of the insertion click is heard (see par. 8.3.8).
• Position “Forward”: brake off.
• Position “Backward to the right”: brake engaged and locked.
7 Button commands See par. 4.3.2.
8 Fuel gauge
It indicates the level of the fuel in the tank.
• Green: fuel quantity.
• Red: reserve.
9 Throttle
Regola il numero di giri del motore.
• Position. “Starter” (full forward):
It facilitates starting of the engine in cold periods (see par. 8.3.2).
• Position “Hare” (forward): it increases engine rpm.
• Position “Turtle” (backward): it lowers engine rpm.
10
Heating temperature
control knob
(option)
It controls the heating temperature.
• Rotated clockwise it increases the temperature.
• Rotated counterclockwise it decreases the temperature.
TAB. 5
4.3.2 Button commands
ATTENTION
THE DISPOSITION OF THE BUTTONS CAN VARY ACCORDING TO THE FITTING OUT.
Ref. Name Function
1 Power switch DC12V
Three-position switch, it powers the socket on the lifting arm to operate any electrical
device on attachment assembled to the machine (eg.: chimney on the snow blower).
The switch has three positions:
• Position “Forward”: it powers the socket (eg.: rotation of the
snow blower to the right).
• Position “Central”: it interrups the supply of the socket.
• Position “Backward”: it reverses the polarity of the socket (eg.:
rotation of the chimney of the snow blower to the left).
cont.
4- DESCRIPTION OF THE MACHINE
