MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
45/70
MultiOne SRL
8.3.5.1 Electrical and hydraulic disconnection
WARNING
CHECK THE ATTACHMENT INSTRUCTION MANUAL WITH REGARDS TO HYDRAULIC AND ELECTRICAL CONNECTIONS.
THE HYDRAULIC PIPES AND ELECTRICAL CABLE MUST BE DISCONNECTED BEFORE DISASSEMBLING MECHANICALLY THE
ATTACHMENT.
1) Press the lock button (FIG. 23 - Ref. 2) on the lock handle and raise the lock handle to the unlocked position
(FIG. 24 - Ref.D and E).
2) Disconnect the attachment’s hydraulic lines from the machine (FIG. 24 - Ref. F).
3) Cover the multi-connector with the rubber cover (FIG. 23 - Ref. 1).
4) Disconnect the electrical plug (if any).
8.3.5.2 Mechanical disconnection of the attachment with manual release system
WARNING
THERE ARE RESIDUAL RISKS N. 1, N.2 AND N.3 (SEE PAR. 3.2).
To disconnect the attachment with manual release system proceeds as follows:
1) Lift and push back the two release levers (FIG. 21 - Ref. 3) from the quick coupler in order to disengage the two plugs.
2) Turn on the machine (see par. 8.3.2).
3) Move to the right the multifunction joystick in order to rotate forward the quick coupler of the machine. If necessary translate
backward a few cm.
4) Move “Forward” the multifunction joystick in order to lower the lifting arm and disassembly the attachment.
8.3.6 Use of the attachment
WARNING
TO USE THE ATTACHMENT PLEASE REFER TO THE INSTRUCTION ATTACHMENT MANUAL.
YOU MUST KEEP THE ATTACHMENT ASSEMBLED TO THE MACHINE MORE CLOSED AS POSSIBLE TO THE GROUND WHEN
MOVING.
8.3.7 Turning off the machine
To turn off the machine proceed as follows:
1) Stop the machine without a steering.
2) Lower the lifting arm and/or put the possible assembled attachment on the ground.
3) Set to the MIN. the accelerator lever, Pos. “Turtle”.
4) Insert the parking brake (see par. 8.3.8).
5) Release the pressure of the hydraulic system as described at par. 8.3.4.2.
6) Put in Pos. “Centre” the hydraulic flow control pedal (FIG. 22 - Ref. 1).
7) Put the key in Pos. “0”.
8) Remove the key from the control panel and store it in a safe place.
OPERATION -8
